RYNAN Oxygen Generator
RYNAN Oxygen Generator ensures a stable supply of high purity oxygen for shrimp ponds. With its fully automated system, it continuously produces and maintains high-quality oxygen. Monitor and control oxygen levels remotely through the TOMGOXY App, minimizing oxygen loss and optimizing oxygen distribution.
Why RYNAN Oxygen Generator?
Enhanced Shrimp Health and Growth
Enhanced Feed Conversion
Increased Survival Rates
Time-Saving and Efficiency
Optimized DO enhances shrimp feeding efficiency, promoting increased activity, appetite, and feed intake. This results in improved feed conversion rates and enhanced shrimp production efficiency.
Proper dissolved oxygen (DO) levels are crucial for shrimp health and growth. Optimal DO supports their overall development, resulting in accelerated growth rates with in lesser time, maximizing productivity.
The TOMGOXY app integrates seamlessly with the RYNAN Oxygen Generator, streamlining monitoring and control. It eliminates the need for manual DO checks and physical operation of the oxygen pumping system, saving valuable time and resources for shrimp farmers.
Sufficient oxygen levels enhance shrimp survival rates by preventing hypoxia-induced mortality. Oxygen-rich water minimizes oxygen deprivation, promoting the overall well-being of shrimps.
RYNAN Oxygen Generator Frequently Asked Questions
-
An oxygen generator for shrimp farming is a system that produces high-purity oxygen (90–95%) on-site using PSA (Pressure Swing Adsorption) technology.
Unlike traditional aerators that rely on atmospheric air, the RYNAN Oxygen Generator delivers concentrated oxygen directly into the pond, improving dissolved oxygen (DO) stability in intensive farming systems.
-
The system separates nitrogen from compressed air to produce concentrated oxygen, which is then dissolved into the pond using a precision oxygenator.
Because the oxygen purity is significantly higher than atmospheric air, oxygen transfer efficiency increases, allowing faster DO recovery and more stable oxygen levels during high biomass or heavy feeding periods.
-
Paddle wheels improve surface aeration but depend on 21% atmospheric oxygen and high motor power.
The RYNAN Oxygen Generator injects 90–95% oxygen directly into water, delivering higher transfer efficiency and reducing reliance on multiple high-horsepower aerators.
This makes it more suitable for high-density shrimp farming where oxygen demand exceeds traditional aeration capacity.
-
Because concentrated oxygen dissolves more efficiently than air, farms require fewer paddle wheels to maintain stable DO levels.
Under optimized farm design conditions, electricity usage can be reduced by up to 70% compared to aerator-heavy intensive systems.
Actual savings depend on pond layout, biomass density, and system configuration.
-
Yes. The system can be retrofitted into circular or rectangular ponds.
However, optimal performance depends on water circulation design. Integration with engineered pond slope and structured circulation systems such as RYNAN MFD improves oxygen distribution and overall efficiency.
A technical assessment is recommended before installation.
RYNAN Oxygen Generator Specifications
PSAU-500
M020PSA
Dimensions
PSAU 500 L x W x H = 1,700 x 1,350 x 2,370 mm
Size
M020PSA L x W x H = 830 x 430 x 950 mm
Dimensions
PSAU 500 1,570 kg
Weight
M020PSA 146 kg
Power
PSAU 500 750 W, 380 VAC, 3 phase 4 wires - 50 Hz
Power Supply
M020PSA 1.5 kW, 220 VAC - 50 Hz
Communication
4G/WIFI and Bluetooth
Display and Communication
Direct control via 7-inch touch screen Remote control via TOMGOXY mobile app
Control
TOMGOXY APP
Discover how RYNAN Aquaculture TOMGOXY Application empowers users with precise shrimp farming capabilities, and comprehensive data accessibility at their fingertips.
